Bobrick

Bobrick QuietDry TrimDry ADA Surface Mount Hand Dryer B-7120

  • Product Code: B-7120
  • Availability: In Stock
  • $615.83

Shipping and tax are calculated during checkout.

Nationwide delivery Secure checkout Product specifications

Available Options

Know your product

Product details

' Offered in two attractive finishes, the TrimDry surface mount hand dryer is a compact, quiet alternative to similar units from Excel and Dyson. Choose between brushed stainless steel or white epoxy finishes. Both units feature steel construction, 71 cfm of airflow, a 1/7 hp motor running at 8000 rpm, and infrared hand sensors. Components are protected by multiple thermal overload switches.

  1. Mounting

    Surface-mounted

  2. Material

    Type 304 stainless steel; Plastic

  3. Finish

    Satin finish

At a glance

Product specifications

SKU / Model
B-7120
Brand
Bobrick
Construction
See template for wall plug and screw installation details. For plaster or dry wall construction, provide concealed backing to
Finish
Satin finish
Material
Type 304 stainless steel; Plastic
Mounting
Surface-mounted
Compliance
ADA; cULus; CE
Warranty
10-Year Limited Warranty — In addition to Bobrick's one-year guarantee, Bobrick extends a limited 10-year warranty from
Operation
bearing at nondrive end. Equipped with automatic thermal-overload switch.
Full product description and documents
' Offered in two attractive finishes, the TrimDry surface mount hand dryer is a compact, quiet alternative to similar units from Excel and Dyson. Choose between brushed stainless steel or white epoxy finishes. Both units feature steel construction, 71 cfm of airflow, a 1/7 hp motor running at 8000 rpm, and infrared hand sensors. Components are protected by multiple thermal overload switches.
  • Two cover designs: type 304 stainless steel with #4 satin finish vertical grain (B-7128) or mild steel zinc plated with high gloss white epoxy paint (B-7120)
  • Hand dryer surface mounts with 20 gauge (1.5mm) steel plate using four mounting holes
  • Two available models to support either 115V or 208–240V electrical systems
  • Swirling circulation of airflow comfortably dries hands in less than 25 seconds
  • Unit saves energy by running only when hands are present (dryer stops as soon as hands are removed from path of sensor)
  • Part of the QuietDry series, with a sound level of 71 dBA
  • Limited 10 year warranty extended by Bobrick
  • Projects 4” (100mm) from finish face of wall. 13 25/32” (350mm) wide by 13 19/32” (345mm) high
  • Dryer dimensions allow ADA compliance when properly installed
  • Download the Bobrick B-7120 Technical Data Sheet (PDF)

Tags: Bobrick, B-7120, Hand Dryers, Satin finish, Type 304 stainless steel, Plastic, ADA, cULus, CE, Surface-mounted
