Bobrick QuietDry TrimDry ADA Surface Mount Hand Dryer B-7120
-
$615.83
Shipping and tax are calculated during checkout.
Available Options
Know your product
Product details
' Offered in two attractive finishes, the TrimDry surface mount hand dryer is a compact, quiet alternative to similar units from Excel and Dyson. Choose between brushed stainless steel or white epoxy finishes. Both units feature steel construction, 71 cfm of airflow, a 1/7 hp motor running at 8000 rpm, and infrared hand sensors. Components are protected by multiple thermal overload switches.
Mounting
Surface-mounted
Material
Type 304 stainless steel; Plastic
Finish
Satin finish
At a glance
Product specifications
- SKU / Model
- B-7120
- Brand
- Bobrick
- Construction
- See template for wall plug and screw installation details. For plaster or dry wall construction, provide concealed backing to
- Finish
- Satin finish
- Material
- Type 304 stainless steel; Plastic
- Mounting
- Surface-mounted
- Compliance
- ADA; cULus; CE
- Warranty
- 10-Year Limited Warranty — In addition to Bobrick's one-year guarantee, Bobrick extends a limited 10-year warranty from
- Operation
- bearing at nondrive end. Equipped with automatic thermal-overload switch.
Full product description and documents
- Two cover designs: type 304 stainless steel with #4 satin finish vertical grain (B-7128) or mild steel zinc plated with high gloss white epoxy paint (B-7120)
- Hand dryer surface mounts with 20 gauge (1.5mm) steel plate using four mounting holes
- Two available models to support either 115V or 208–240V electrical systems
- Swirling circulation of airflow comfortably dries hands in less than 25 seconds
- Unit saves energy by running only when hands are present (dryer stops as soon as hands are removed from path of sensor)
- Part of the QuietDry series, with a sound level of 71 dBA
- Limited 10 year warranty extended by Bobrick
- Projects 4” (100mm) from finish face of wall. 13 25/32” (350mm) wide by 13 19/32” (345mm) high
- Dryer dimensions allow ADA compliance when properly installed
- Download the Bobrick B-7120 Technical Data Sheet (PDF)
Tags: Bobrick, B-7120, Hand Dryers, Satin finish, Type 304 stainless steel, Plastic, ADA, cULus, CE, Surface-mounted
